EK 120/42
Product Overview
Features
Choose your battery system: Bosch or Makita
All data can be easily read via Bluetooth
Open head, rotatable
Quality assurance via visual and audible signals in case of error
Simple and safe: one-button operating concept for controlling all tool functions
Effortless working due to balanced centre of gravity
LED for work area illumination
2-stage hydraulic system with fast feed and power stroke
Simple and safe: automatic retraction when operation is complete
Automatic retract stop (ARS) for positioning control in case of multiple crimps
Always ready-to-use thanks to battery charge and service display
suitable for:
13-series interchangeable crimping dies, wide crimping
Technical Specifications
Crimping force120 kN
Stroke/opening width42 mm
Crimping range 16-400 mm²
Crimping cycle 8 s to 9 s (depending on crimping cross-section)
Number of crimps approx. 115 at 150 mm² Cu DIN
Battery voltage 18 V
Battery capacity 4.0 Ah, Li-Ion
Battery charging time 36 mins
Weight including battery 7.1 kg
Ambient temperature -12 °C to + 40 °C
