Technical Specifications
Maximum Operating Pressure10,000 psi (700 bar)
Pressure Rating 1st Stage200 psi (14 bar)
Pressure Rating 2nd Stage10,000 psi (700 bar)
Cylinder CompatabilitySingle-acting
Pump TypeTwo Speed
Reservoir Capacity453 in3 (7423 cm3)
Usable Oil Capacity453 in3 (7423 cm3)
Maximum Flow at Rated Pressure.29 in3/stroke (4,75 cm3/stroke)
Oil Displacement per Stroke 1st Stage7.69 in3 (126,20 cm3)
Oil Displacement per Stroke 2nd Stage0.29 in3 (4,75 cm3)
Maximum Handle Effort110 lbs (49 kg)
Piston Stroke1.5 in (38,1 mm)
Valve OperationManual
Power SourceManual
Weight61 lbs (27,7 kg)
